Product Details:

Place of Origin: China
Brand Name: GrowBetter, 1/3, OEM
Certification: CE ROHS FCC
Model Number: BRI-H250S-H-260

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Inner Box, Export Cartons, OEM
Delivery Time: 5-7 days for S/O, 15-35 days for PO
Payment Terms: 30% deposit, 70% before delivery
Supply Ability: 10000 set per month
Get Best Price Contact Now

Detail Information

Material: Aluminum Style: Electronic
Usage: HID, High Intensity Discharge Matched Tube: HPS, MH, CMH, CDM, XED
THD: <10% PFC: >0.95
Highlight:

Aquarim Lights Digital Greenhouse Ballast

,

1.77A Digital Greenhouse Ballast

,

250W dimmable digital ballast

Product Description

250W Dimmable Digital Greenhouse Ballast MH Lamp digital electronic ballast for Aquarim Lights





Advantages and characteristics

1, energy saving

The ballast itself consumes less power, saves 40% more power than an inductive ballast, increases light efficiency by 12%, and has a ballast power factor greater than 0.96.



2, constant power, extend the life of the light source

The light source starts quickly without flicker, so that the color temperature and brightness of the light source do not change with voltage fluctuations. The constant low-frequency operating current output will not produce acoustic resonance phenomenon, reduce the damage to the lamp, and extend the life of the light source by 30%.



3, environmental protection, low noise and no pollution

Low harmonic content, no interference with the power grid and other equipment, low noise and no radiation.



4, to achieve intelligent control

With over-voltage, over-current, open circuit, short circuit, temperature and many other protection features, fire safety is guaranteed. Dimmable and smart control.



5, for a wide range of ambient temperatures

Use a wide range of ambient temperature, low temperature rise, -25 C ~ +55 C



Specification Model BRI-H150S-H-192 BRI-H250S-H-260
Material Aluminum Aluminum
Dimension 192*100*63mm 260*100*63mm
Net Weight 820g 1320G
Style Electronic Electronic
Usage HID, High Intensity Discharge HID, High Intensity Discharge
Matched Bulb HPS, MH, CMH, CDM, XED HPS, MH, CMH, CDM, XED
Technical Parameters Input Voltage 165~265VAC 165~265VAC
Input Current 1.77A~0.62A 1.69A~1.05A
Input Power 163W±3 270W±5
Input Frequency 50Hz~60Hz 50Hz~60Hz
Surge Current <20A <20A
Power Factor >0.95 >0.95
THD <10% <10%
Input Insurance 250V/4A 250V/4A
Ouput Power 150W±3 250W±5
Lamp Voltage 75V~150V 75V~150V
Output Frequency 160Hz±10Hz 160Hz±10Hz
Crest Factor <1.7 <1.7
Open Circuit Protection >300V >300V
Ignition [striking] voltage <5KV <5KV
Short-circuit protection YES YES
Open-circuit protection YES YES
Ignition failure protection YES YES
Thermal protection YES YES
Lamp failure protection YES YES
Low-voltage protection YES YES
Ballast to Lamp distance <5m <5m
Working temperature -25℃~+50℃ -25℃~+50℃
Min starting temperature -25℃ -25℃
EMC EN55015,FCC18C EN55015,FCC18C
Support dimming YES YES
Dimming setting 2-phase time control
3-phase time control
2-phase time control
3-phase time control
Packaging Inner Box Size
Carton Package 39*27*29.5 cm 39*27*29.5 cm
Package Qty. 15pcs/carton 10pcs/carton
Package G.W. 11.8kg 13.8KG
Package CBM
