315W CDM Grow Light Ballast Dimmable Digital Electronic CMH
Product Details:
Place of Origin: | China |
Brand Name: | GrowBetter, 1/3, OEM |
Certification: | CE ROHS FCC |
Model Number: | BRI-H315S-EU-260 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 |
---|---|
Price: | Negotiable |
Packaging Details: | Inner Box, Export Cartons, OEM |
Delivery Time: | 5-7 days for S/O, 15-35 days for PO |
Payment Terms: | 30% deposit, 70% before delivery |
Supply Ability: | 10000 set per month |
Detail Information |
|||
Material: | Aluminum | Dimension: | 260*100*63mm |
---|---|---|---|
Input Voltage: | 165~265VAC | Output Power: | 315 W |
Power Factor: | >0.95 | THD: | < 10% |
High Light: | 315W Grow Light Ballast,CDM Grow Light Ballast,CMH Digital Ballast |
Product Description
High Efficient Grow Light Ballast low frequency dimmable digital electronic ballast for 315W CMH CDM Grow light Bulb
Run 315W CMH CDM Lamp.
Low frequency
High power factor PF>0.95
Low harmonic General harmonic THD≤ 10%
High light efficiency and energy saving.
Low power consumption
More lumens: 20-30% more lumens than magnetic ballasts
Constant output of power and light when voltage varies between -15%~15% of rating voltage
Open circuit and short circuit protection functions available.
Ignition failure protection
Overheat protection
Easy installation Easy to hang the lamp, no need any external starter and compensation capacitor.
Completely silent: no more humming and buzzing.
Constant output of power when voltage fluctuate with no flickering
No fans inside, water resistance and maintenance free operation.
Model | BRI-H315S-EU |
Material | Aluminum |
Dimension | 260*100*63mm |
Net Weight | 1320g |
Matched Bulb | HPS/MH/CDM/XED |
Input Voltage | 165~265VAC |
Input Current | 2.15A~1.34A |
Input Power | 345W±5 |
Input Frequency | 50Hz~60Hz |
Surge Current | <20A |
Power Factor | >0.95 |
THD | <10% |
Input Insurance | 250V/4A |
Ouput Power | 315W±5 |
Lamp Voltage | 75V~150V |
Output Frequency | 160Hz±10Hz |
Crest Factor | <1.7 |
Open Circuit Protection | >300V |
Ignition [striking] voltage | <5KV |
Short-circuit protection | YES |
Open-circuit protection | YES |
Ignition failure protection | YES |
Thermal protection | YES |
Lamp failure protection | YES |
Low-voltage protection | YES |
Ballast to Lamp distance | <5m |
Working temperature | -25℃~+50℃ |
Min starting temperature | -25℃ |
EMC | EN55015,FCC18C |
Support dimming | YES |
Dimming setting | 3 phase manual dim |
Inner Box Package | |
Outer Carton Package | 390*270*330mm |
Package Qty. | |
Package G.W. |
